TZIDC, TZIDC-200 DIGITAL POSITIONER | COI/TZIDC/TZIDC-200-EN REV. B 45
Positioner without function
Connect 4 to 20 mA.
Is the display active?

Swap the connection wires + and −. Now
is the display active?

Good job!
The work activities are completed.
No Yes

Yes

No
Check the power source or return
defective positioners for repair.
Connect compressed air.
Now is it working?

Good job!
The work activities are completed.
Yes

No
Switch the positioner to operating mode
1.2 (manual). Press the arrow button
briefly.
Press the second arrow.
Now is it working?

Start Autoadjust. Save parameters and
switch the positioner to operating mode
1.1. In case of error messages, check the
mechanical configuration.
Now is it working?

Good job!
The work activities are completed.
Yes Yes

No

No
Check the safety position of the
pneumatic output module and compare
with the IP-Typ parameter. The safe
position must be activated (FAIL_POS)
before the parameter can be changed.
Save parameters.
Now is it working?
Press the  button to read the current
value.
Is the current value correct?

Check power source or PLS.
No

Yes

Good job!
Work activities are
over after starting
Autoadjust!
Yes

No
Return the defective positioner for
repair.
Switch the
function for the
digital input
(FUNCTION) to
none.
