ABB WGA631 - Horizontal Displacement

50
25
x45
6
19
3
°
3
°
1
4
3
°
3
°
44
1x45
GUID-4B194DC1-C58E-4C47-8A13-9F4F703018D1 V1 EN
Figure 4: End cover for the waveguide tube, 1VB8001476
3.1 Horizontal displacement
The wireless communication system works properly with the horizontal
displacement of Z < 5 mm between the waveguide tubes. Larger gaps are not
allowed because the transmitting power should be limited to 0 dBm.
1MRS755551 B Section 3
Mounting requirements
WGA631 11
Installation and commissioning manual
