ABB WGA631 - Page 47

Table 10: Enclosure
Description Value
Electrostatic discharge test, class IV According to IEC 61000-4-2
• For contact discharge +/- 8 kV
• For air discharge (without LED) +/- 8 kV
Radio frequency interference tests
• Conducted, common mode According to IEC 61000-4-6
10 V (rms), f = 150 kHz...80 MHz
• Radiated, amplitude-modulated According to IEC 61000-4-3
10 V/m (rms), f = 80...3000 MHz
Table 11: Ethernet and WGA port
Description Value
Fast transient disturbance tests, class III According to IEC 61000-4-4
2 kV
Radio frequency interference tests According to IEC 61000-4-6 and IEC 60255-22-6
• Conducted, common mode 10 V (rms), f = 150 kHz...80 MHz
CE approval Complies with the EMC directive 89/336/EEC and
the LV directive 73/23/EEC
Table 12: Standard tests
Mechanical tests
Vibration tests (sinusoidal) According to DNV
Table 13: Power consumption
Description
Value
Running ~ 5 W
1MRS755551 B Section 7
Technical data
WGA631 39
Installation and commissioning manual
