System Specifications
OPTIS™ Integrated Next Operation and Maintenance Manual – 600173796 Rev. A 39
Table 2. System Safety and Regulatory Specifications (continued)
Category Specifications
Leakage and Auxiliary Current
Chassis Leakage Current
< 100 µa rms normal condition
< 500 µa rms single-fault condition
Patient Leakage Current
Measured at patient end of DOC:
< 10 µa rms normal condition
< 50 µa rms single-fault condition
System - Electrical and Physical
Table 3. System Electrical and Physical Specifications
Parameter Specification
System Cabinet Power Input
Line Voltage
100/120/220/240 VAC ±10%, user selectable
50/60 Hz ±1 Hz
Power Consumption
Active: < 400 VA
Standby: <60 VA
Radio Specifications
Drive Motor and Optical Controller (DOC)
Frequency Range
13.553 - 13.567 MHz (ISM-band)
Type
Amplitude-Shift Keying (ASK)
Radiated Power
Effective Radiated Power (ERP):-43.05 dBm
Tableside Controller (TSC) Bluetooth
‡
Module
Frequency Range
2.400 - 2.4835 GHz (ISM-band)
Type
GFSK, DQPSK, 8-DPSK
Radiated Power
Bluetooth
‡
power Class 1
FFR Receivers
Frequency Range
2.4 -2.4835 GHz (ISM-band)
Type
Frequency hopping spread spectrum (FHSS)
Range
Up to 4 m
Note: Radio range is reduced by objects and walls. Keep
Transmitter and receiver in line of sight wherever
possible.
Delay Time
<20 ms
Transport and Storage Conditions (permissible ranges)
Ambient Temperature
-20 to +50 degrees C
Relative Humidity
25% - 90%, non-condensing
Operating Conditions
Ambient Temperature
+10 to +32 degrees C
Relative Humidity
30% to 85%, non-condensing
Mechanical Specifications - System Cabinet
Weight
50.8 kg (112 lbs)
Dimensions
60 x 34 x 61 cm
Mechanical Specifications - 19” Monitor
Weight
9 lbs (4 kg)
Dimensions
22 x 41 x 41 cm
Mechanical Specifications - DOC Holster
Weight
3.0 lbs (1.4 kg)
Dimensions
16 x 12 x 25 cm
