System Overview
20
OPTIS™ Integrated Next Operation and Maintenance Manual – 600173796 Rev. A
System Components
The OPTIS Integrated Next includes the following components, integrated into a
catheterization laboratory:
• System cabinet, which includes an isolation transformer
• Laser imaging engine
• Computer
• Drive motor and optical controller (DOC)
• DOC holster
• Keyboard, monitor, mouse
• Tableside controller (TSC)
Note:
• Use only the power cable and accessories provided with the system. Use
of other cables or accessories may negatively affect electromagnetic
compatibility performance.
• Physiology procedures require a Wi-Box™ AO Transmitter installed in the
catheterization laboratory. Contact Abbott Service for more information.
CAUTION:
The above components are integral parts of the OPTIS Integrated
Next
. The hardware and software must not be modified in any way by the
customer
. Making such modifications may interfere with correct operation and
will void system warranties.
Contact an Abbott Technical Service representative
for more information.
Note: The OPTIS Integrated Next can only be installed and serviced by an
Abbott Technical Service representative. The Service representative has access
to all necessary maintenance instructions and component parts lists. Contact an
Abbott Technical Service representative whenever there is new construction in
the catheterization lab.
