System Specifications
OPTIS™ Integrated Next Operation and Maintenance Manual – 600173796 Rev. A 41
Electromagnetic Emissions
Table 6. Guidance and Manufacturer's Declaration - Electromagnetic Emissions
The OPTIS Integrated Next is intended for use in the electromagnetic environment specified below. The customer or user of the OPTIS Integrated
Next should ensure that it is used in such an environment.
Emissions Test
Compliance
Electromagnetic Environment Guidance
RF emissions
CISPR 11
Group 1
The OPTIS Integrated Next uses RF energy only for its internal function.
The
refore, its RF emissions are very low and not likely to cause any
interf
erence with nearby electronic equipment.
RF emissions
CISPR 11
Class A
The emission characteristics of the OPTIS Integrated Next are suitable for
use in industrial areas and hospitals (CISPR 11 class A). System should not
be used in a residential (domestic) environment (CISPR 11 class B is
required in support of domestic use)
.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations / flicker emissions
IEC-61000-3-3
Complies
Note: The emission characteristics of this equipment make it suitable for use in industrial areas and hospitals (CISPR 11
class A). If it is used in a residential environment (for which CISPR 11 class B is normally required), this equipment might
not offer adequate protection to radio-frequency communication services. The user might need to take mitigation
measures, such as relocating or re-orienting the equipment.
Electromagnetic Immunity
Table 7. Guidance and Manufacturer's Declaration - Electromagnetic Immunity
The device is intended for use in the electromagnetic environment specified below. The customer or the user of the device should ensure that it is
used in such an environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment - Guidance
Electrostatic discharge
(ESD)
EN 61000-4-2
(IEC 61000-4-2)
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
Floors should be wood, concrete, or ceramic tile. If floors are
covered with synthetic material, the relative humidity should be
at least 30%.
Electrical fast
transient / burst
EN 61000-4-4
(IEC 61000-4-4)
±2 kV for power supply
lines
±1 kV for input / output
lines
±2 kV
±1 kV
Mains power quality should be that of a typical commercial or
hospital environment.
Surge
EN 61000-4-5
(IEC 61000-4-5)
±1 kV differential mode
±2 kV common mode
±1 kV
±2 kV
Mains power quality should be that of a typical commercial or
hospital environment.
Voltage dips, short
0% U
T
; 0.5 cycle
100% dropout in
Mains power quality should be that of a typical commercial
interruptions, and
At 0 ° , 45 ° , 90 ° , 135 ° ,
VNOM for 0.5 cycle at
or hospital environment. If the user of the device requires
voltage variation on
180 ° , 225 ° , 270 ° and
listed phase angles
continued operation during power mains interruptions, it is
power supply input
315 °
recommended that the device be powered from an
lines.
IEC 61000-4-11
0% U
T
; 1 cycle
and
100% dropout in
VNOM for 1 cycle at 0 °
uninterruptible power supply or a battery.
70% U
T
; 25/30 cycles
30% dropout in VNOM
Single phase: at 0 °
for 25/30 cycles at 0 °
0% U
T
; for 5 sec @ 60 Hz
100% dropout in
(300 cycles)
VNOM for 5 sec
0% U
T
; 250/300 cycles
100% interrupt in
VNOM for 250/300
cycles
