American Beer Equipment 2001 SW 6
th
St.
Lincoln, NE 68522
13
d. Seaming Adjustment Guide
Characteristic Reason A Reason B Reason C
Long Seam Height Die #1 set too far from chuck Die #2 set too close to chuck
Long Body Hook Lift table high/Pressure high Die #1 too far from chuck
Long Cover Hook Die #1 too close to chuck
Short Body Hook Lift table low/Pressure low Die #1 too close to chuck Die #2 too far from chuck
Short Cover Hook Lift table too high Die #1 too far from chuck
A more comprehensive table, provided by Ball Beverage, can be found in Figure 28.
Figure 6. Pin Gauge Height
Gauge
Height
