Figure 7- Lift Table Assembly. The lift-table puck height (pin gauge height) can be adjusted by loosening or tightening the adjustment knob.
Figure 8- Roller Assembly. Roller height can be adjusted by loosening the socket head cap screw and turning the roller assembly in or out. The
roller’s position can be fixed by tightening the socket head cap screw to 14.5 ft*lbs.
LIFT
-
TABLE COVER
LIFT TABLE PUCK
SOCKET HEAD CAP SCREW
SEAMING
CYLINDER
ROLLER
PIN HEIGHT
ADJUSTMENT
KNOB
