Abit Fatal1ty FP-IN9 SLI User Manual

2-2 FP-IN9 SLI
2.1 SoftMenu Setup
This option configures the CPU’s clock and voltage.
Phoenix – AwardBIOS CMOS Setup Utility
SoftMenu Setup
Brand Name: Intel(R) Core(TM)2 CPU 6300 @ 1.86GHz Item Help
Frequency : 1866.7 MHz
Parameters Setting Current
SLI-Ready Memory Disabled Disabled
CPU Operating Speed 1866(266)
x
- FSB:Memory Ratio Auto
x
- FSB (QDR) Auto 1066.7
Estimated New FSB (QGR) 1066.7
Estimated New CPU Clock 1866.7
x
- MEM (DDR2) Auto 800.0
Estimated DDR2 data Rate 800.0
x
- Multiplier Factor 7 X 7 X
NB PCIe X16 Clock 100MHz 100
Voltages Control Default
x
- CPU Core Voltage Auto 1.3250V
x
- DDR2 Voltage Auto 1.85 V
x
- DDR2 REF Voltage Auto 0.0%
x
- CPU VTT Voltage Auto 1.20 V
x
- NB Voltage Auto 1.20 V

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Brand Name
This item displays the CPU model name installed on this motherboard.
Frequency
This item displays the processor speed of the CPU installed on this motherboard.
SLI-Ready Memory
This item selects the SPD profile for SLI-Ready memories. The configuration options may vary
depending on the type of module you installed.
※ The following items become configurable when the item “SLI-Ready Memory”
is set to [Enabled].
CPU Operating Speed
This item displays the CPU operating speed according to the type and speed of your CPU. Select
the [Linked] or [Unlinked] mode to enter the manual option.
Manual Option:
※ The wrong settings of the multiplier and external clock in certain
circumstances may cause CPU damage. Setting the working frequency higher
than the PCI chipset or processor specs, may cause abnormal memory module
functioning, system hangs, hard disk drive data lose, abnormal functioning of
the VGA card, or abnormal functioning with other add-on cards. Using
non-specification settings for your CPU is not the intention of this explanation.
These should be used for engineering testing, not for normal applications.
※ There will be no guaranty for the settings beyond specification. Any damage of
any component on this motherboard or peripherals resulting therein is not our
responsibility.
