2-2 IP35/IP35-E
2.1 SoftMenu Setup
This option configures the CPU’s clock and voltage.
Phoenix – AwardBIOS CMOS Setup Utility
SoftMenu Setup
Brand Name: Intel(R) Core(TM)2 CPU 6400 @ 2.13GHz Item Help
Frequency : 2.17GHz
CPU Operating Speed 2133(266)
x
- External Clock 272MHz
x - Multiplier Factor
8 X
x
- Estimated New CPU Clock 2176MHz
x
- DRAM Speed (CPU:DRAM) Default
x
- PCI Express Frequency 100MHz
Voltages Control Default
x
- CPU Core Voltage 1.3000V
x
- DDR2 Voltage 1.80V
x
- CPU VTT Voltage 1.20V
x
- ICH 1.50V Voltage 1.50V
x
- MCH 1.25V Voltage 1.250V
x
- CPU GTLREF 63.0%

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Brand Name
This item displays the CPU model name installed on this motherboard.
Frequency
This item displays the processor speed of the CPU installed on this motherboard.
CPU Operating Speed
This item displays the CPU operating speed according to the type and speed of your CPU. You
can also select the [User Define] option to enter the manual option.
User Define:
※ The wrong settings of the multiplier and external clock in certain
circumstances may cause CPU damage. Setting the working frequency higher
than the PCI chipset or processor specs, may cause abnormal memory module
functioning, system hangs, hard disk drive data lose, abnormal functioning of
the VGA card, or abnormal functioning with other add-on cards. Using
non-specification settings for your CPU is not the intention of this explanation.
These should be used for engineering testing, not for normal applications.
※ There will be no guaranty for the settings beyond specification. Any damage of
any component on this motherboard or peripherals resulting therein is not our
responsibility.
- External Clock
This item selects the external clock frequency. Due to the specification limit of the CPU you
installed, the speed you set over its standard bus speed is supported, but not guaranteed.
