Abit IP35-E - 1 Hardware Setup; Specifications

Hardware Setup
IP35/IP35-E 1-1
1. Hardware Setup
1.1 Specifications
CPU
• LGA775 socket for Intel processor of:
Core 2 Extreme Edition / Core 2 Quad /
Core 2 Duo, &
Pentium Extreme Edition / Pentium Dual
Core / Pentium D / Pentium 4.
• Supports FSB 1333MHz
Chipset
• IP35: Intel P35 / Intel ICH9R
• IP35-E: Intel P35 / Intel ICH9
Memory
• 4x 240-pin DIMM slots support
maximum memory capacity up to 8GB.
• Supports Dual Channel DDR2 800/667
Un-buffered Non-ECC memory.
LAN
• Onboard Gigabit LAN Controller
Audio
• Onboard 7.1-Ch HD Audio Codec
• Supports Auto Jack Sensing and S/PDIF
Out
• HDMI Audio Header Ready
Serial ATA
• IP35: 6x SATA 3Gb/s connectors
offered by Intel ICH9R support Intel
Matrix Storage Tech (AHCI & RAID 0, 1,
5, and 10).
• IP35-E: 4x SATA 3Gb/s connectors
offered by Intel ICH9.
IEEE 1394 (For IP35 only)
• Supports 2x IEEE 1394a ports at
400Mb/s transfer rate.
Expansion Slots
• 1x PCI-E X16 Slot
• 2x PCI-E X1 Slots
• 3x PCI Slots
Internal I/O Connectors
• 1x Floppy Port
• 1x Ultra ATA 133 IDE Connector
• 6x SATA 3Gb/s Connectors
(For IP35
only)
• 4x SATA 3Gb/s Connectors
(For IP35-E
only)
• 4x USB 2.0 Headers
• 1x IEEE 1394 Header
(For IP35 only)
• 1x FP-Audio Header
• 1x CD-In Honnector
• 1x S/PDIF Out Header
Rear Panel I/O
• 1x PS/2 Keyboard Connector
• 1x PS/2 Mouse Connector
• 1x Optical S/PDIF Out Connector
• 1x 7.1-Ch Audio Connector
• 1x IEEE 1394 Connector
(For IP35 only)
• 4x USB 2.0 Connectors
• 1x RJ-45 Gigabit LAN Connector
abit Engineered
• abit SoftMenu
™
Technology
• abit Silent OTES
™
Technology (For IP35
only)
RoHS
• 100% Lead-free Process and RoHS
Compliant
Miscellaneous
• ATX Form Factor (305mm x 245mm)
• Vista Premium HW Ready
※ Specifications and information contained herein are subject to change without
notice.
