2-10 IP35/IP35-E
- CAS Latency Time (tCL)
- RAS# to CAS# Dealay (tRCD)
- RAS# Precharge (tRP)
- Precharge Delay (tRAS)
- Refresh Cycle Time (tRFC)
- Write Recovery Time (tWR)
- Write to Read Delay (tWTR)
- Act to Act Time (tRRD)
- Read to Precharge (tRTP)
 PCIe Root Port Function
Click <Enter> key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
PCIe Root Port Function
PCI Express Slot 1 Auto Item Help
PCI Express Slot 2 Auto
PCIe Compliancy Mode v1.0a

:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
PCI Express Slot 1 / PCI Express Slot 2
This option enables or disables the PCI Express port function.
PCIe Compliancy Mode
This item selects the mode for PCI Express add-on card.
 Back to Advanced Chipset Features Setup Menu
Init Display First
This item allows you to choose the primary display card.
PEG Force X1
When set to [Enabled], this item forces the PEG port down to x1 mode.
