2-6 IP35 Pro
 Voltage Monitoring
Click <Enter> key to enter its submenu:
μGuru Utility v1.01C
ABIT EQ
Voltage Monitoring
Reading Shutdown
Enable
Beep
Enable
High
Limit
Low
Limit
(*)CPU Core Voltage 1.25 V (*) (*) 1.60 V 0.00 V
(*)DDR2 Voltage 1.80 V ( ) (*) 2.15 V 1.45 V
(*)DDR2 VTT Voltage 0.89 V ( ) (*) 1.05 V 0.70 V
(*)CPU VTT 1.2V Voltage 1.20 V ( ) (*) 1.50 V 1.00 V
(*)MCH 1.25V Voltage 1.25 V ( ) (*) 1.50 V 1.00 V
(*)ICHIO 1.5V Voltage 1.50 V ( ) (*) 1.80 V 1.20 V
(*)ICH 1.05V Voltage 1.05 V ( ) (*) 1.25 V 0.85 V
(*)ATX +12V (24-Pin Connector) 12.00 V ( ) (*) 14.40 V 9.60 V
(*)ATX +12V (8-Pin Connector) 12.00 V ( ) (*) 14.40 V 9.60 V
(*)ATX +5V 5.00 V ( ) (*) 6.00 V 4.00 V
(*)ATX +3.3V 3.30 V ( ) (*) 3.95 V 2.65 V
(*)ATX 5VSB 5.00 V ( ) (*) 6.00 V 4.00 V
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit
All Voltages
These items display the voltage of each element.
- Shutdown Enable
Use <Space> key to enable system shutdown function. If the voltage of corresponding element
is higher/lower than the high/low limit, the system will automatically shutdown.
- Beep Enable
Use <Space> key to enable warning beeps function. If the voltage of corresponding element is
higher/lower than the high/low limit, warning beeps will sound.
- High/Low Limit
These items set the high and low voltage limit.
※ The high limit voltage must be set higher than the low limit voltage.
