Abit KN9S - PC Health Status

3.8 PC Health Status
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Shutdown Temperature 95°C/203°F Item Help
CPU Warning Temperature 80°C/176°F
FAN Fail Alarm Selectable CPUFAN1
CPU FANEQ Control Enabled
- FanEQ Target Temperature 55°C/131°F
- FanEQ Temp. Tolerance 5°C/ 41°F
- FanEQ Start Control 80%
- FanEQ Stop Control 50%
CPU Temperature 42°C/107°F
System Temperature 30°C/100°F
PWM Temperature 42°C/107°F
CPU FAN Speed 3245 RPM
SYS FAN Speed 0 RPM
AUX1 FAN Speed O RPM
AUX2 FAN Speed O RPM
CPU Core Voltage 1.42 V
DDRII Voltage 2.10 V
ATX +3.3V 3.30 V
DDRII VTT Voltage 1.00 V
PCIE Voltage 1.50 V
ATX +12V 12.00 V
ATX +5V 5.00 V
↓↑ →← :Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Shutdown Temperature
You can set the processor shutdown temperature here. If the processor temperature exceeds
the settings value, system will force to shutdown to protect the processor not overheat.
CPU Warning Temperature
This item lets you select the temperature at which you want the system to send out a warning
message to the PC speakers of when the temperature goes beyond either limit. You can select
the temperatures you want.
FAN Fail Alarm Selectable
This item selects the fan that will be monitored for malfunction.
CPU FANEQ Control
This item allows you to control the CPU fan speed. When set to [enabled], the following items
become selectable.
- FanEQ Target Temperature
This item allows you to set a wanted temperature for the CPU.
- FanEQ Temp. Tolerance
This item sets the high/low limits of the target temperature.
3-20 KN9 SLI, KN9 Ultra, KN9S
