Introduction 1-1
Chapter 1. Introduction
1-1. Features & Specifications
1. CPU
• Supports AMD-K7 Duron/Athlon/Athlon XP/Barton Socket A 200/266/333/400 MHz FSB
2. Chipset
• NVIDIA nForce2 Ultra 400 chipset with MCP (NF7)
• NVIDIA nForce2 IGP chipset with MCP (NF7-M)
• NVIDIA nForce2 Ultra 400 chipset with MCP-T (NF7-S)
• NVIDIA nForce2 Ultra 400 chipset with RAID MCP (NF7-S2/NF7-S2G)
• Integrated 128-bit memory controller
• Supports Advanced Configuration and Power Interface (ACPI)
• AGP (Accelerated Graphics Port) connector supports AGP 8X/4X (0.8V/1.5V)
3. Dual DDR
• Dual DDR architecture combines two independent 64-bit memory controllers
• Dual DDR 400 provides up to 6.4GB/s bandwidth for system memory
4. Memory
• Three 184-pin DIMM slots
• Supports 3 DIMMs DDR 200/266/333 (Max. 3GB)
• Supports 2 DIMM DDR 400 (Max. 2GB)
• Supports DDR 400 only when using an add-on VGA card (NF7-M)
5. Audio
• Onboard 6-Channel AC 97 CODEC
• Professional digital audio interface supports optical S/PDIF OUT (NF7/NF7-S/NF7-M)
• NVIDIA SoundStorm
™
Technology with real-time Dolby Digital 5.1 encoder (NF7-S)
6. LAN
• Onboard 10/100M LAN Controller (NF7/NF7-S/NF7-M/ NF7-S2)
• Onboard 10/100/1000M LAN Controller (NF7-S2G)
7. ABIT Engineered
• ABIT SoftMenu
™
Technology
• ABIT FanEQ
™
Technology
• ABIT CPU ThermalGuard
™
Technology
• ABIT FlashMenu
™
User’s Manual
