O-4 Appendix O
SL6
5
*
. OS/APPLICATION: Indicate the operating system and applications your are running
on the system.
Example: MS-DOS
®
6.22, Windows
®
95, Windows
®
NT....
6
*
.CPU: Indicate the brand and the speed (MHz) of your CPU.
Example:(A) In the “Brand” space, write “Intel”, in the “Specifications” space, write
“ Pentium
®
II MMX 300MHz”
。
7. HDD: Indicate the brand and specifications of your HDD(s), specify if the HDD is using
4IDE1 or 4IDE2. If you know the disk capacity, indicate it and check (“5”) “
”; in
case you give no indication, we will consider that your HDD is “6IDE1” Master.
Example: In the “HDD” space, check the box, in the Brand space, write “Seagate”, in the
Specifications space, write “ST31621A (1.6GB)”.
8. CD-ROM Drive: Indicate the brand and specifications of your CD-ROM drive. Specify
if it uses 4 IDE1 or 4IDE2
，
and check (“5”) “
”; in case you give no indication, we
will consider that your CD-ROM is “6IDE2” Master.
Example: In the “CD-ROM drive” space, check the box, in the Brand space, write
“Mitsumi”, in the Specifications space, write “FX-400D”.
9. System Memory (DRAM): Indicate the brand and specifications (SIMM / DIMM) of
your system memory. For example:
In the Brand space, write “Panasonic”, in the Specifications space, write “SIMM-FP
DRAM 4MB-06”.
Or, in the Brand, write “NPNX”, in the Specifications space, write “SIMM-EDO DRAM
8MB-06”.
Or, in the Brand space, write “SEC”, in the Specifications space, write “DIMM-S
DRAM 8MB-G12”.
10. ADD-ON CARD: Indicate which add-on cards you are absolutely sure are related to the
problem.
If you cannot identify the problem’s origin, indicate all the add-on cards inserted into
your system.
Note
Items between the “*” are absolutely necessary.
