3-30 Chapter3
SL6
Rx2Tx2. If you choose RxD2, TxD2, your motherboard must support a COM port IR KIT
connection. Otherwise, you can only choose the IR-Rx2Tx2 to use the IR header on your
motherboard to connect your IR KIT. Please use the default setting.
Onboard Parallel Port:
Sets the I/O address and IRQ of the onboard parallel port. Four options are available:
Disable ) 3BC/IRQ7 ) 378/IRQ7 ) 278/IRQ5. Default setting is 378/IRQ7.
✏
✏✏
✏ Parallel Port Mode:
Four options are available: SPP ) EPP ) ECP ) ECP+EPP. The default setting is
SPP mode.
✏
✏✏
✏ EPP Mode Select:
Two options are available: EPP1.7 ) EPP1.9. The default setting is EPP 1.7. When the
mode selected for the parallel port mode is EPP, the two EPP version options are
available.
✏
✏✏
✏ ECP Mode Use DMA:
Two options are available: 1 ) 3. The default setting is 3. When the mode selected for
the parallel port mode is ECP, the DMA channel selected can be Channel 1 or Channel 3.
PWRON After PWR-Fail:
This setting lets you set the system action after a power failure. Three options are available:
On ) Former-Sts ) Off. The default setting is Off.
Game Port Address:
Three options are available: Disabled ) 201 ) 209. The default setting is 201. This item
sets the address of the onboard game port connector.
Midi Port Address:
Four options are available: Disabled ) 330 ) 300 ) 290. The default setting is 330. This
item sets the address of the onboard midi port connector.
