3-18 Chapter 3
VL6
PCI#2 Access #1 Retry:
Two options are available: Disabled or Enabled. The default setting is
Enabled
. This item
allows you enable/disable the PCI #2 Access #1 Retry. When you set the PCI#2 Access#1 to
Enabled, the AGP bus will attempt to access the PCI bus at a limited time period before
being disconnected. When you set it to Disabled, the AGP bus will try to access the PCI bus
until it successfully accesses the PCI bus.
AGP Master 1 WS Write:
Two options are available: Disabled or Enabled. The default setting is
Disabled
. This
implements a single delay when writing to the AGP Bus. When you set it to Disabled, two-
wait states are used by the system, allowing for greater stability.
AGP Master 1 WS Read:
Two options are available: Disabled or Enabled. The default setting is
Disabled
. This
implements a single delay when reading to the AGP Bus. By default, two-wait states are
used by the system, allowing for greater stability.
OnChip Sound:
Two options are available: Disabled or Enabled. The default setting is
Enabled
. Because this
motherboard had built-in the Audio CODEC, so we set this item to Auto. If you want to use
the other sound card with this motherboard, you have to disable this item.
OnChip Modem:
Two options are available: Disabled or Enabled. The default setting is
Enabled
. As this
motherboard can use the modem riser card, you need to set it to “Enabled” in order to auto
detect the device. If you want to use the other internal modem card with this motherboard,
you have to disable this item.
Memory Parity/ECC Check:
Two options are available: Disabled or Enabled. The default setting is
Disabled
. This item
can allow BIOS to check memory is parity/ECC module or not.
