Introduction of VL6 Features 1-3
User’s Manual
!
Hardware monitoring
：
Included fan speed, voltages, CPU and system environment
temperature
!
Board size: 305 * 190mm
"
""
" Supports Wake On LAN, Modem, but your ATX power supply 5V standby power
must be able to provide at least a 720mA current capacity. Otherwise, the functions
may not work normally.
#
The 66MHz/100MHz/133MHz bus speeds are supported but not guaranteed due to the
PCI, processor and chipset specifications.
#
Specifications and information contained in this manual are subject to change without
notice.
Note
All brand names and trademarks are the property of their respective owners.
1-3.
Layout Diagram
Figure 1-2. VL6 Motherboard component location
