Abit VL6 User Manual

1-2 Chapter1
VL6
The VL6 has built-in hardware monitoring functions (you can refer to
Appendix J
for
detailed information), they can monitor and protect your computer insuring a safe
computing environment. The motherboard can provide high performance for servers and
meets the requirements for desktop systems for multimedia in the future.
1-2. Specifications
1. CPU
!
Supports Intel
®
Pentium
®
III 500 ~ 1GHz processors (Based on FC-PGA package)
!
Supports Intel
®
Celeron™ 300A~733MHz processors (Based on 66MHz PPGA & FC-
PGA package)
!
Supports 66, 100 and 133MHz CPU external clock speeds
!
Reserves support for future Intel
®
Pentium
®
III processors
2. Chipset
!
VIA Apollo Pro 133 chipset (VT82C693A and VT82C686A)
!
Supports Ultra DMA/33 and Ultra DMA/66 IDE protocol
!
Supports Advanced Configuration and Power Management Interface (ACPI)
!
Accelerated Graphics Port connector supports AGP 1x and 2x mode (Sideband) 3.3V
device
3. Memory (System Memory)
!
Three 168-pin DIMM sockets support SDRAM modules
!
Supports up to 768MB MAX. (8, 16, 32, 64, 128, and 256MB SDRAM)
!
Supports ECC
4. System BIOS
!
CPU SOFT MENU™ II, can easily set the processor parameters
!
Award Plug and Play BIOS supports APM and DMI
!
Write-Protect Anti-Virus function by AWARD BIOS
5. Multi I/O Functions
!
Two Channels of Bus Master IDE Ports supporting up to four Ultra DMA 33/66 devices
!
PS/2 keyboard and PS/2 mouse connectors
!
One floppy port connector ( up to 2.88MB)
!
One parallel port connector (EPP/ECP)
!
Two serial ports connectors
!
Two USB connectors
!
On board USB header for two extra USB channels
!
Built-in IrDA TX-RX header
!
Audio/Game connectors (Line-in, Line-out, MIC-in, and Game Port connectors)
6. Audio CODEC Features
!
AC ’97 2.1 compliant
!
Integrated hardware Sound Blaster Pro

AC ‘97 digital audio controller
7. Miscellaneous
!
ATX form factor
!
One AGP slot, five PCI slots, one ISA slot and one AMR slot
!
Built-in Wake on LAN header
!
Built-in IrDA TX/RX header
!
Built-in Wake On Modem header
!
Built-in SM bus header
