ABL eMH1 User Manual

INTRODUCTION
7
Package contents and unpacking
Your eMH1 charging station is delivered with a range of accessory components, which
are necessary for the proper operation of the device. Therefore, please check immedi-
ately after unpacking whether the following components are included:
COMPONENT QUANTITY DESCRIPTION
eMH1 charging
station
1
Charging station comprising lower and upper
housing part and cover shield with integrated
lock
Instruction Manual 1
Manual for operating the charging station (this
document)
Key 2
Key for locking the housing cover shield
Drilling template 1 Template for drilling the holes for wall mounting
Should one or more components be missing after unpacking, please contact your local
distributor immediately: You can find the necessary contact details on page ii in
this manual.
Available accessories
ABL sells additional accessories for your eMH1 charging station. For the models of the
EVSE 5X2 series, the following components are available:
DESIGNATION PART NUMBER QUANTITY
Type 2 charging cable
for connection with all eMH1 charging stations
and vehicles with charging sockets according to
IEC 62196-2, Type 2, 32 A 240 / 415 V AC and
IP44 splash protection rating
Length: approx. 4 meters
LAK32A3 1
Adapter cable Type 2 to Type 1
for connection to all eMH1 charging stations with
charging sockets according to IEC 62196-2, Type 2,
with charging connector according to IEC 62196-2,
Type 1, 32 A 230 V AC, and IP44 splash protection
rating
Length: approx. 4 meters
LAKT2T1 1

ABL eMH1 Specifications

General

Model	eMH1
Category	Battery Charger
Charging Power	3.7 kW
Connector Type	Type 2
Protection Class	IP54
Operating Temperature	-25°C to +40°C
Charging Current	16 A
Input Voltage	230 V
