APPENDIX
22
Appendix
Specifications
MODEL VARIANT EVSE 502 EVSE 512 EVSE 522
Compliance IEC 61851-1/22
Rated voltage 230/400 V 50 Hz 230 V 50 Hz 230/400 V 50 Hz
Rated current
16 A (MCB
required onsite)
32 A (MCB
required onsite)
16 A (MCB
required onsite)
Max. output 11 kW 7.2 kW 11 kW
Charging socket Type 2, lockable
Circuit-protection devices
RCCB, Type A, 30
mA and electronic
DC fault current
detector DC-RCM,
I
Δn d.c.
≥ 6 mA
RCCB, Type A,
30 mA
RCCB, Type B,
30 mA
Energy meter not included
Control / Customization internal RS485-interface
Terminal block up to 4 mm
2
up to 6 mm
2
up to 4 mm
2
Operating temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Degree of protection
(housing)
IP44
Overvoltage category II III
Dimensions 272 x 220 x 106 mm (H x W x D)
Weight per unit ca. 2.3 kg
