APPENDIX
23
MODEL VARIANT EVSE 552 EVSE 562 EVSE 572
Compliance IEC 61851-1/22
Rated voltage 230/400 V 50 Hz 230 V 50 Hz
Rated current 32 A (MCB required onsite)
Max. output 22 kW 7.2 kW
Charging socket Type 2, lockable
Circuit-protection devices
external RCCB
required onsite
RCCB, Type A, 30
mA and electronic
DC fault current
detector DC-RCM,
I
Δn d.c.
≥ 6 mA
Energy meter not included
Control / Customization internal RS485-interface
Terminal block up to 6 mm
2
Operating temperature -30°C to 50°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Degree of protection
(housing)
IP44
Overvoltage category III II
Dimensions 272 x 220 x 106 mm (H x W x D)
Weight per unit ca. 2.3 kg
WARNING!
Please note that the charging stations of the eMH1 series are available
in a range of model variants with differing technical data. The information
and technical specifications in this manual refer exclusively to the model
variant mentioned in these instructions and must NOT UNDER ANY CIR-
CUMSTANCES be transferred to other eMH1 model variants.
Standards & guidelines
Your eMH1-EVSE 5X2 charging station complies with the following standards and
classes of protection:
General standards
STANDARD DESCRIPTION
2004/108/EC EMC Guideline
2002/95/EC RoHS Guideline
