INSTALLATION AND POWER SUPPLY CONNECTION

DANGER!

The above color-coding is NOT internationally standardized: Should the in-

dividual wires in the power supply cable be color-coded differently, please

immediately contact a qualified electrical contractor! Have the power

supply checked and replaced if necessary.

After successful connection to the power supply by a qualiﬁed specialist or electrical

contractor, please take the following steps to complete installation:

1. Replace the upper part of the housing.

2. Fix the upper part of the housing to the rear part using the appropriate screws.

3. Switch the integrated or onsite FI residual current circuit breaker (RCCB) back on.

4. Lock the cover shield of the EVSE 5x2 using the key supplied and store the key in

a safe place.

5. Switch the MCB in your domestic power distribution box back on.

PLEASE NOTE:

We recommend that you take your charging station into operation in the

presence of a qualified installer: He or she will be able to assess the

proper functioning of the charging station and correct any malfunctions

or installation errors that may occur.
