ABL WALLBOX eMH2 EN User Manual

Appendix – Technical specifications |
31
Appendix
Technical specifications
Model code 2W22Y1 / PZ42D-T0C01 2W22X1 / PZ42D-L0C01
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 22kW
Charging connection Type 2 charging socket
Phase system 3-phase
Terminal block Direct connection to RCD, PE to rail mount terminal block, max. 5 × 16mm²
Residual Current Devices Type A RCD, 30mA
DC fault current detection
DC-RCM, I
Δn d.c.
≥ 6mA
Energy meter MID compliant
Load switching Contactor, 4-pole
Weld detection Contactor welding trips RCD
Charge controller EVCC2
RFID ISO14443A/B, 4-byte/7-byte UID only
Backend communication OCPP 1.6 via LAN or LTE/WIFI (optional)
Compliance IEC 61851-1
Control / customization Internal RS485 interface, bus system
Operating temperature -30°C to 40°C
Storage temperature -30°C to 85°C
Relative humidity 5 to 95% (no condensation)
Class of protection I
Degree of protection (housing) IP44/IP54 (plugged/unplugged)
Overvoltage category III
Impact strength IK08
Dimensions (HxWxD) 437×328×170mm
Weight per unit Approx. 8kg
Model code 2W22Y2 / PZ42D-T0C11 2W22X2 / PZ42D-L0C11
Rated voltage 230/400V
Grid frequency 50Hz
Current 32A
Maximum output 22kW
Charging connection Type 2 charging socket with shutter
Phase system 3-phase
Terminal block Direct connection to RCD, PE to rail mount terminal block, max. 5 × 16mm²
Residual Current Devices Type A RCD, 30mA
DC fault current detection
DC-RCM, I
Δn d.c.
≥ 6mA
Energy meter MID compliant
Load switching Contactor, 4-pole
Weld detection Contactor welding trips RCD
Charge controller EVCC2
RFID ISO14443A/B, 4-byte/7-byte UID only
Backend communication OCPP 1.6 via LAN or LTE/WIFI (optional)
Compliance IEC 61851-1
Control / customization Internal RS485 interface, bus system
