Appendix – Data cable recommendations |
33
Data cable recommendations
The following data cables are recommended for wiring up the bus interfaces in the Wallbox eMH2:
Designation Properties Number
J-Y(ST)Y...LG 4 × 2 × 0.22 mm²
1 cable per connection between
two wallboxes
A-2Y(L)2Y...ST III BD 4 × 2 × 0.8 mm²
Cat5 UTP -
Cat6 UTP -
LiYCY (TP) 4 × 2 × 0.75 mm²
Please note that these are recommendations only: the conductor cross-section must be adjusted accord-
ing to the cable length by the specialist electrical contractor responsible for installation.
CE certification and compliance declaration
The Wallbox eMH2 carries the CE mark. A copy of the declaration of compliance is displayed below.
