Installation – Tools and accessories required |
9
 Ideally, the installation site should provide a ready
connection to the electricity grid. Otherwise, a
separate power supply cable must be installed.
 In order to operate group installations, suitable
data cables must also be installed in the instal-
lation site (see also "Preparing and fixing the
wallbox in place" on page 11 as well as "Data
cable connections" on page 14).
Tools and accessories required
For mechanical installation, you will need the following components included with the wallbox:
 Drilling template,
1pc
× 1
× 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
