19
INTERNAL CONNECTIONS
Power-supply cord through
the end of housing
Power-supply cord through
the base plate
ABLOY
Max 200 mm
Max 200 mm
The power supply cord shall not be
- routed through doorways, window openings, walls,
ceilings, floors or the like.
- attached or otherwise secured to the building structure.
- concealed behind walls and the like.
Be sure that the power cord is not entrapped in
moving parts of the operator, door or system.
Warning!
Note!
