TECHNICAL DATA
The automatic swing door operator is intended for both new and existing swing
door applications, internal and opening out external doors. The automatic
swing door operator can be used in residential units, institutions, shops, public
buildings, warehouses and offices.
Operating conditions
For use in dry premises, temperature
range -10...+50 C
Stored in dry premises, temperature
range -30...+85 C
The automatic swing door operator
must not be installed in applications
where it is subjected to water or snow
o
o
Technical data
Supply voltage 115/230 V AC
50/60 Hz, Rated output 50 W
Stabilized voltage from operator to
impulse devices and electric locks
12 and 24 V DC
Enclosure class IP 20
Micro-processor control
Programmable adjustment of all door
movement functions
Operator dimensions and door
weights shown in installation drawings
