Installation and Operating Instructions 3
ABS lifting station PiranhamatABS lifting station Piranhamat
1 General
1.1 Application areas
ATTENTION The maximum allowable temperature of the medium pumped is 40°C
The Piranhamat 100/120 lifting unit has been specially designed for pumping away of efuent from a WC which
lies below the sewer backwash level, e.g. in cellars, etc. Where ow by gravity into the sewer system is not
possible. They are suitable for installing either at the initial building stage or for retro tting to existing buildings.
It is possible to connect a wash-hand basin, a shower and a bidet to the unit.
NOTE The Piranhamat 100/120 is recommended for single family houses only, or single
rooms. Not for public or constant use.
NOTE Whenusingaexiblehoselineensurethattheconnectionsareleaktightatthe
maximum operating pressure.
The Piranha-system shreds faecal efuent and allows it to be pumped through pipes of smaller diameter (from
DN 25) or through exible hose. It is important to note that the Piranhamat 100/120 is not a sanitary disposal
unit, although it may shred particular sanitary items dropped accidentally into the WC.
m
The lifting unit may not be used for the collection or pumping of ammable liquids. A maximum of
one toilet, one wash-hand basin, and one shower tray may be connected for normal domestic use.
In addition, the regulations of the Institute for Building Technology require that access to another WC
above the sewer backwash level must also exist.
NOTE Where the users are anonymous members of the public and usage cannot be
monitoredorwheremoreefuentsourcesaretobeconnectedwerecommendthe
installation of the Sanimat series
1.2 Technical Data
Maximum noise level ≤ 70dB. This may be exceeded in certain circumstances.
Head H (m) 1 2 3 4 6 8
Flow Q (m3/h) 7,0 5,8 5,0 4,7 4,3 3,2
Flow Q (l/s) 2,0 1,6 1,4 1,3 1,2 0,9
Tank with integral pump Discharge Motor Rated Rated Cable Weight
Connection Power P1 Voltage Current Length Complete
Piranhamat DN25/32 1.1 kW 220/240V 4.7A 2.0m 9.0Kg
