Absen A Series - Module and Cabinet Dimensions; Product Components

A series user manual
6 / 24
Service Hotline:400-700-3278
1.4 Module size
320mm x 320mm
1.5 Cabinet size
1.6 Product device
Auxiliary cabinet：960 x 960mm
Standard cabinet：1280 x 960mm
Auxiliary cabinet：960 x 640mm
Auxiliary cabinet：1280 x 640mm
Module
receiving card
Switching power
supply
Mounting holes
Handle hole
HUB board
Wire hole
The back cover
Positioning column
Masks
