Page 13AN120076.000_EN
6.2 Regulations
The load indicator systemLIS–SE is in accordance with
the following codes and standards:
NSR 20014/35/EG (low voltage)
EMC 2014/ 30/EG (electromagnetic compatibility)
EN 61000- 6- 4 (interference emission)
EN 61000- 6- 2 (resistance to interferences)
Electrical installation work must be performed in accor-
dance with the following general codes and standards:
IEC 60364- 5- 56
Requirements for the installation of power systems with
rated voltages up to 1000V
EN 60204- 32
Safety of machinery: Electrical equipment of machines;
requirements for hoists.
For special applications, other standards and regula -
tions may also be applicable.
Safety warnings:
You must not carry out any work inside the
unit.
In the event of a defect in anLIS–SE unit, please contact
our service department.
In order to avoid the risk of serious injury and severe da-
mage, only persons qualified to work on electric power
systems may w ork on the units. Before installing any
commissioning the units, these persons must carefully
read the operating instructions and observe the s afety
instructions.
Attention!
Any modifications to ABUS products and any
partsinstalledinoronABUSproductswhich
could impair the safety of the products must
be approved by the manufacturer. ABUS will
not be liable for any injury, loss or damage
which may occur as a result of modifications
which have not been approved or the use of
products other than for the intended pur-
pose.
Note:
ELECTROMAGNETIC COMPATIBILITY
The unit has been designed in accordance
with the E MC directive no. 2014/30/EG.
_________________________________
7 Malfunctions
7.1 Causes and Remedies
TheLIS–SE displays the following error codes on the operator terminal or the load display.
Err–Code
Explanation Remedy
Err 1 Current correction factor not entered Enter current correction factor in parameter P 1.3
Err 2 Ratedloadcapacitynotset Enter load capacity in parameter P 0.1
Err 3 Unit not set Set unit with known load
Err 6 Is displayed when parameter P 2.3 is selected
Setting load too low or setting/connection
error
Increase load to 80 % of rated load capacity
Err 7 Setting not correctly completed seepage14
Err 8 Data save error Replace unit
Err 9 Data read error Press ”Enter” until the function returns. Otherwi-
se, replace unit
U_I Measured rotor power input <10 Watt Check the basic setting of the unit; if the setting
is OK, the problem has probably been caused by
the wiring factor.
The input and output voltage data required for trouble-
shooting are stated in Section 4 ”Technical Data”.
If any other malfunctions occur, please contact our ser-
vice centre (see Section 7.2).
7.2 Service
Notes:
The ABUS Service Centre can be reached
day and night.
