Page 20 Data : 01.03.2016
Adjustment:
It is only possible to read out the data of the load popu-
lation recorder if the recorder has been enabled. Only
ABUS can enable the load population recorder.
If the load population recorder is not enabled, it is not
possible to call up any data for t he recorder.
If the load population recorder has been enabled and
activated, the data can be called up on menu level 1 af -
ter entering CODE 2223.
Parameter: P5.3
Acceptance test
This parameter can be used to switch the outputs of the
LIS–SE manually (main lift, precision lift, Y1 and Y2).
In this mode of operation, the overload protection
function is overridden (no overload shut–down).
Caution: The switch contacts are always switched in
accordance w ith the control signal received.
Value on
display
Function
1 lifting/lowering not possible
2 slow lifting/lowering possible
3 fast lifting/lowering possible
4 –––
5 –––
(0 = contact open, 1 = contact closed)
You must leave this parameter following each test.
If the LIS- SE continues to be set to this parameter, the
hoist will operate, but the overload protection function
will be deactivated. For this reason, a time limit has
been incorporated for this parameter. When this para-
meter has been selected for about 45 minutes, the
LIS- SE is switched automatically back to normal ope-
ration, and the overload protection function is active
again.
Parameter: P5.4
Max. cycles (inching)
This parameter can only be accessed using a special
CODE.
Adjustment
This parameter is set to 16.
Parameter: P5.5
Delete all parameters (except
load population recorder
values)
It ca n only be accessed using CODE 1443.
Caution !!
This parameter deletes all parameters except
for those of the load population recorder.
Parameter: P
6.1 Enter starting value
This parameter is used to enter a starting value (in
hours) which must be deducted from the theoretical
hours at full load when calculating the remaining ser -
vice life.
(For example, this parameter is used when installing a
newLIS–SEonanexistingsystem.)
Adjustment:
This parameter has two levels:
1. Level 1 = display stored starting value
2. Level 2 = set new starting value
CODE 1443 must be entered in order to access level 2.
Parameter: P6.2
Display actual hours of use S
To display the value stored, press Enter.
Parameter: P6.3
Display total operating hours Ti
To display the value stored, press Enter.
Parameter: P6.4
Enter FEM group
This parameter is used to set the FEM group and to ac-
tivate the load population recorder. It can only be used if
the load population recorder has been enabled by
ABUS.
Adjustment:
This parameter can only be enabled by ABUS.
The theoretical service life stated by the manufacturer
is entered (in hours at full load). (See also table 1 in FEM
9.755.)
Parameter: P6.5
Erase all values of load popula-
tion
recorder
This parameter is used to erase the values stored in the
load population recorder
Adjustment
A special CODE must be entered in order to access this
parameter.
Parameter: P7.0
Password (code) input for level 3
When this parameter is selected, level 3 can be acces-
sed by entering a code. This code no. is only available
to ABUS.
Parameter: P9.9
Quit parameter level
This parameter is used to quit the parameter setting
mode. The hoist is then ready for operation and the
overload protection function is active.
Further Information
1. Parameter P 0.1 must always be set in accordance
with the load capacity of the hoist.If this parameter
is not set correctly, the shut–down point of the over -
load protection device may be too high or too low.
2. TheLIS–SE should be adjusted using a load of 80 %
or more of the rated load capacity. At this load, the
accuracy is as specified.
The minimum load which can be used for adjust-
ment is 40 % of rated load capacity. However, the
specified a ccuracy cannot a lways be reached at
this value.
If it is only possible to adjust the unit with a load bet-
ween 40 % and 80 % of rated load, this must be sta-
ted in the test report (failure to comply with speci -
fied tolerances).
