Abus LIS-SE - Page 24

Page 24 Data : 01.03.2016
No.
Key
Description Display
34
+
Enter
enter known load, working from right to left
confirm each digit with ENTER
10.50 e.g.
flashing
35
Enter
after the last digit has been confirmed by pressing ENTER, the display
flashes briefly: known load is stored. the display on the right appears
Pro 1
36
HT
FH
no load (empty hook)
Press FH until hoist motor shuts down (about 5 sec.)
The unit completes measurement and storage automatically. Following stor-
age, the hoist motor is shut down.
The rotating field power stored is then displayed (in kW) until the key is
released. The procedure must not be interrupted.
0.542
e.g.
After releasing
button
Pro 2
37
HT
HH
no load (empty hook)
Press HH until hoist motor shuts down (about 5 sec.).
The unit completes measurement and storage automatically. Following stor-
age, the hoist motor is shut down.
The rotating field power stored is then displayed (in kW) until the key is
released. The procedure must not be interrupted.
1.025 e.g.
After releasing
button the bar
runs from bot-
tom left to top
right.
38
HT
FH
lift known load at precision speed until it is suspended freely
This function is enables for 15 min. If confirmation is not given by pressing
emergency shut–down (as described under point 33) within this time, the-
LIS–SE switches back to normal mode. The setting must then be repeated
(points 1 to 4 and then from point 25 onwards).
The b ar runs
from bottom
left to top right.
39
HT
Emergency
shut–down
press ”Not–Aus” (emergency shut–down)
The key must be pressed for more than 5 sec.
After resetting
emergency off
Pro 3
40
HT
FH
known load on hook
Press FH until hoist motor shuts down (about 5 sec.).
The unit completes measurement and storage automatically. Following stor-
age, the hoist motor is shut down.
The rotating field power stored is then displayed (in kW) until the key is
released. The procedure must not be interrupted.
0.722 e.g.
After releasing
button
Pro 4
41
HT
HH
known load on hook
Press HH until hoist motor shuts down (about 5 sec.)
The unit completes measurement and storage automatically. Following stor-
age, the hoist motor is shut down.
The rotating field power stored is then displayed (in kW) until the key is
released. The procedure must not be interrupted.
3.623 e.g.
After the button
has been
released, SP
flashes briefly
and ABUS then
runs across the
screen. The
display is:
00.00
