Display Setting
Example:
Input
Display
1250 kg 1.250
10250 kg 10.25
7. 0 The underlined digit flashes.
8. The hoist motor resistance is the resistance measured in one phase.
The measurement must be made on the hoist motor using an ohmmeter or multimeter.
Measurements on motors with star circuits
(Y).
Measurement
between neutral point and U1 = resistance on one phase = input value for P 1.2
between U1 and V 1 = resistance in two phases = input value for P 1.2 =
is reading divided by 2
Measurements on motors with delta circuit (
)
between U1 and V1 = input value for P 1.2 =
is reading divided by 2
