Abus LIS-SE - Page 28

Page 28 Date: 01.03.2016
Voltage range 3Y
(380 – 415 V; 50 Hz. // 440 – 480 V; 60 Hz.)
Hoist motor Current measuing module
No.
Hoist
Type
Motor
Type
(Input P1.1)
P
[KW]
at 50 Hz.
12 / 2 pole
In
[A]
12 / 2 pole
R – I nput for
P1.2 (in Ohms)
12/2–pole
Measu-
ring
range
In
[A]
Current
measuing
module
Correction
factor
AN Remarks
13 GM 5000 H.3
10
2,9 / 18,8 12,2 / 34,0 3,97 / 0,27
IV
36
1381
9746
14 GM 6000 L 3
11
2,9 / 18,8 12,2 / 34,0 3,97 / 0,27
IV
36
1381
9746
15 Reserve 16 GM 7000 L
13
2,4 / 16 11 / 29,5 4,48 / 0,42
IV
36
1381
9746 1 motor
17 GM 7000 H
14
4,8 / 32 22 / 59 2,24 / 0,212
V
60
2344
9747 2 motors
18 GM 7000 M
15
3/20 13,5 / 39,5 3,97 / 0,27
IV
36
1381
9746 1 motor
19 GM 7000 U
16
6/40 27 / 79 1,99 / 0,135
VI
136
5169
19682 2 motors
20
R measured [U–V] R phase one motor
R Input = R phase R phase = –––––––––––––––– or R phase = R measured [Y –U] for 2 motors R Input = ––––––––––––––––
2 2
