Abus LIS-SE - Page 32

Page 32 Date: 01.03.2016
Voltage range 5Y
(460 – 500 V; 50 Hz. // 550 – 600 V; 60 Hz.)
Hoist motor Current measuing module
No.
Hoist
Type
Motor
Type
(Input P1.1)
P
[KW]
at 50 Hz.
12 / 2 pole
In
[A]
12 / 2 pole
R – I nput for
P1.2 (in Ohms)
12/2–pole
Measu-
ring
range
In
[A]
Current
measuing
module
Correction
factor
AN Remarks
13 GM 5000 H.3
0
2,9 / 18,8 10,2 / 28,3 5,6 / 0,414
IV
36
1381
9746
14 GM 6000 L 3
0
2,9 / 18,8 10,2 / 28,3 5,6 / 0,414
IV
36
1381
9746
15 Reserve 16 GM 7000 L
0
2,4 / 16 9,2 / 24,6 6,15 / 0,64
IV
36
1381
9746 1 motor
17 GM 7000 H
0
4,8 / 32 18,4 / 49,2 3,075 / 0,32
V
60
2344
9747 2 motors
18 GM 7000 M
0
3/20 11,3 / 33 5,6 / 0,414
IV
36
1381
9746 1 motor
19 GM 7000 U
0
6/40 22 / 66 2,8 / 0,207
V
60
2344
9747 2 motors
20
R measured [U–V] R phase one motor
R Input = R phase R phase = –––––––––––––––– or R phase = R measured [Y–U] for 2 motors R Input = ––––––––––––––––
2 2
