Voltage range 1Y
(300 V – 335 V; 50 Hz. // 360 – 400 V ; 60 Hz.)
Hoist motor Current measuing module
No.
Hoist
Type
Motor
Type
(Input P1.1)
P
[KW]
at 60 Hz.
12 / 2 pole
In
[A]
12 / 2 pole
R – I nput for
P1.2 (in Ohms)
12/2–pole
Measu-
ring
range
In
[A]
Current
measuing
module
Correction
factor
AN Remarks
13 GM 5000 H.3
0
3,5 / 22,6 15,3 / 43 2,6 / 0,15
V
60
2344
9747
14 GM 6000 L 3
0
3,5 / 22,6 15,3 / 43 2,6 / 0,15
V
60
2344
9747
15 Reserve 16 GM 7000 L
0
2,9 / 19,2 11,6 / 31 2,79 / 0.268
IV
36
1381
9746 1 Motor
17 GM 7000 H
0
5,8 / 38,4 23,2 / 62 1,4 / 0,134
V
60
2344
9747 2 Motoren
18 GM 7000 M
0
3,6 / 24 14,2 / 42 2,6 / 0,15
V
60
2344
9747 1 Motor
19 GM 7000 U
0
7,2 / 48 28,4 / 84 1,3 / 0,075
VI
136
5169
19682 2 Motoren
20
R measured [U–V] R phase one motor
R Input = R phase R phase = –––––––––––––––– or R phase = R measured [Y–U] for 2 motors R Input = ––––––––––––––––
2 2
