Accu-Chek Performa Nano User Manual

4. Turn the code chip over so the
code number faces away from
you. Push it into the code chip slot
until it stops.
5. Leave the code chip in the meter
until you open a new box of test
strips.
Notes:
Do not force the code chip into the meter. It is designed to go into the meter only •
one way.
If you see a code “- - -” on the display, insert a code chip into the meter.•
10
43149_NanoPerf_24MSTR_Ins.indd 1043149_NanoPerf_24MSTR_Ins.indd 10 11/25/08 2:48:59 PM11/25/08 2:48:59 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
