Accu-Chek Performa Nano User Manual

Transferring Data Directly to a Computer or PDA Using
Specialized Software and an Infrared Cable
You can transfer your stored results to a computer to track, identify patterns, and
print.
Infrared (IR)
Window
1. Install the software according to the instructions. To
transfer the results to a computer, connect the
infrared cable according to the instructions.
2. Run the software program and follow the
instructions about how to download information.
Make sure the software is ready to accept data from
the meter.
3. With the meter off, press and hold both
and
until two arrows on the display alternately flash.
4. Locate the infrared (IR) window on the top of the
meter.
5. Locate the IR window on either the infrared cable
(computer) or PDA.
48
43149_NanoPerf_24MSTR_Ins.indd 4843149_NanoPerf_24MSTR_Ins.indd 48 11/25/08 2:49:06 PM11/25/08 2:49:06 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
