Accu-Chek Performa Nano User Manual

Here is how to mark a test result and initiate a post-meal reminder:
Perform a test. Do not remove the test strip.
1. Press and release
to toggle through the test result markers and post-meal reminder.
Pre-Meal Marker
Pre-Meal Marker with Post-Meal Reminder
Post-Meal Marker
General Marker
2. When the test result marker (
, , or ) or pre-meal marker with post-meal reminder
(
) that you wish to select appears on the display, remove the test strip from the
meter.
If you select the post-meal reminder, the meter beeps one or two hours after the •
pre-meal test to remind you to do a post-meal test.
If you select a test result marker, it is automatically stored in memory.•
18
Note: The post-meal marker automatically appears with the test result if a
test is performed 15 minutes before or after the post-meal reminder is
programmed to beep. Set the post-meal reminder time to one or two
hours in the set up mode.
43149_NanoPerf_24MSTR_Ins.indd 1843149_NanoPerf_24MSTR_Ins.indd 18 11/25/08 2:49:01 PM11/25/08 2:49:01 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
