Accu-Chek Performa Nano User Manual

You need the meter, a test strip, a lancing device designed for AST, and a
lancet.
1. Prepare the lancing device.
2. Insert the test strip into the meter in
the direction of the arrows. The meter
turns on.
3. Make sure the code number on the
display matches the code number on
the test strip container. If you miss
seeing the code number, remove the
test strip and reinsert it into the meter.
21
43149_NanoPerf_24MSTR_Ins.indd 2143149_NanoPerf_24MSTR_Ins.indd 21 11/25/08 2:49:02 PM11/25/08 2:49:02 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
