Accu-Chek Performa Nano User Manual

4. Press and release or to
switch between “On” and “OFF.”
5. If you want to set up more options,
press and release
. If you want to
exit, press and hold
until you see
the flashing test strip symbol.
36
43149_NanoPerf_24MSTR_Ins.indd 3643149_NanoPerf_24MSTR_Ins.indd 36 11/25/08 2:49:04 PM11/25/08 2:49:04 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
