Accu-Chek Performa Nano User Manual

The meter is not
coded or the code
chip is not inserted.
Turn off the meter
and recode it.
68
The test strips will expire
at the end of the current
month. Before the end of
the month, insert a new
code chip from a new
box of test strips and
ensure the code chip
number matches the
code number on the test strip container.
Make sure the time and date in the meter
are correct.
43149_NanoPerf_24MSTR_Ins.indd 6843149_NanoPerf_24MSTR_Ins.indd 68 11/25/08 2:49:09 PM11/25/08 2:49:09 PM

Accu-Chek Performa Nano Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Battery Life	Approximately 1000 tests
Dimensions	69 x 43 x 20 mm
Display	LCD
Memory Capacity	500 results
Automatic Power Off	90 seconds
Battery	1 x 3V lithium battery (CR2032)
Test Strip	Accu-Chek Performa
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Measurement Range	0.6 - 33.3 mmol/L
Weight	Approx. 40 g (with battery)
Operating Conditions	6°C to 44°C, 10% to 90% RH
