Chapter 3 139
Replacing the Modem Module
1. Locate and replace the Modem Module as
shown.
2. Connect the Modem cable to the Modem Module
as shown.
3. Connect the RJ-11 port to the leftside of the
Lower Cover.
4. Replace the adhesive tape to secure the Modem
cable to the Lower Cover.
