Chapter 3
73
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Item
Screw
Color
Part No.
A
M2 x L3
Black
8
6.00D29.620
D
M2 x L5
Black
86.00E32.725
F
M2 x L4
Black
86.00F24.724
H
M2.5 x L8
Black
86.00E34
.738
82
84
