118 Chapter 3
4. Connect the Power Save Board to the Function Board by inserting the FFC and closing the FFC lock as
shown.
Replacing the Switch Cover
CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is
recommended that only fingers are used to remove the Switch Cover.
1. See “Removing the Battery Pack” on page 49.
2. See “Removing the Hinge Covers” on page 63.
3. Place the switch board on the keyboard.
4. Connect the power board to the main unit by inserting the FFC and closing the FFC lock as shown.
To Next Page
