Acer Aspire 5739G - LCD Module Disassembly Process; LCD Module Disassembly Flowchart; Removing the LCD Bezel

78 Chapter 3
3. Remove the single securing screw from the Multifunction board.
4. Lift the Multifunction Board clear of the casing.
Removing the Modem Module
1. Remove the Upper Base. See “Removing the Upper Base” on page 72.
Step Size Quantity Screw Type
Multifunction
Board
M2.5*3 1
