Acer Aspire 5739G - Removing the TV Tuner and Power Switch Board

Chapter 3 57
4. Remove the two screws securing the ODD bracket and remove the ODD bracket from the optical disk drive
module.
5. Press down on the locking catch to release the ODD cover and remove.
Removing the TV Tuner
1. See “Removing the Lower Cover” on page 51.
Step Size Quantity Screw Type
ODD Bracket M2*3 2
