Acer Aspire 5739G - Removing the Speaker Modules

76 Chapter 3
2. Lift the FFC locking latch, as shown, to disengage the cable and disconnect the main board FFC.
3. Open the FFC locking latch as shown and remove the FFC.
4. Remove the three securing screws on the bracket.
Step Size Quantity Screw Type
Finger Print
Reader
M2*3 1
